Schlüter-DILEX-MOP  Plastic expansion joint profile

Schlüter-DILEX-MOP is an expansion joint profile with sturdy serrated lateral sides made of rigid, recycled PVC and a grey, soft PVC expansion zone between the lateral sections for use in screed applications. It is available in three heights, from 35 to 65 mm.


  • Foot traffic
  • Shopping carts
  • Cars
  • Lift trucks
  • Trucks (max. weight 25 t)

Schlüter-DILEX-MOP  Plastic expansion joint profile

Product image DILEX-MOP 1©Schlüter-Systems KG
Cross-section drawing DILEX-MOP 1©Schlüter-Systems KG
zoom_out_map search
Product image DILEX-MOP 1
Cross-section drawing DILEX-MOP 1










  •










  •










  •










  •










  •










  •










  •










  •










  •










  •











General product information

What this product does

Schlüter-DILEX-MOP is a profile with sturdy serrated lateral sections made of recycled rigid PVC and a centre movement zone made of soft PVC. The profile is available in three different heights and is installed as a movement joint in coverings set in a mortar bed, e.g. pavers, ceramic tiles, and natural or man-made stone. It separates individual installation segments in the covering and absorbs minor compressive stresses in the soft PVC movement zone. Since the profile does not have lateral frictional anchoring in the mortar bed, it is not suited for absorbing any tensile stresses that may be present.

The lateral sections of the profile are made of rigid PVC and protect the edges of the adjacent covering from mechanical stresses caused by conveyor vehicles, subject to the limited mechanical suitability of PVC profiles in edge protection. The lateral profile sections are made of environmentally-friendly recycled PVC and may vary slightly in colour. The profiles are therefore primarily intended for industrial applications.

DILEX-MOP may also be tapped into saw-cut joints or inserted into wider joint cuts, e.g. as part of renovation projects. The remaining joint space between the tile and the profile must be filled completely with grout or epoxy.

How to install this product

  1. Select the profile height according to the height of the assembly.
  2. Set the profile flush against the edge of completed covering segments. The lateral profile parts must be solidly embedded in the mortar.
  3. Install the adjacent covering segment flush with the top edge of the profile and solidly embed it in the mortar.
  4. Fill the remaining joint space between the profile and the covering completely with grout.

Installation note on joint repair:

Insert or tap the profile into the appropriately prepared joint chamber and fill the joint space between the profile and the covering completely with grout, epoxy, or dry-set mortar.

What this product is made from

Schlüter-DILEX-MOP features lateral sections made of recycled rigid PVC and a movement zone made of soft PVC at the top.

Material properties and areas of application

The profile is resistant to most chemicals encountered in tiled environments.

In special cases, the suitability of materials must be verified based on the anticipated chemical, mechanical, and/or other stresses.

DILEX-MOP is installed as an expansion joint profile in tile and paver coverings set into a mortar bed. The profile separates the individual installation segments of the covering and absorbs minor compressive stresses in its soft PVC movement zone.

How to look after this product

Schlüter-DILEX-MOP is resistant to fungi and bacteria and requires no special maintenance or care. The profile can be cleaned with regular household detergents when cleaning the tile covering.
