Schlüter-LIPROTEC-LLE  90° corners and end caps

  • Schlüter-LIPROTEC-LLE/I 90° internal corners
  • Schlüter-LIPROTEC-LLE/E 90° external corners
  • Schlüter-LIPROTEC-LLE/EK are the corresponding end caps

  • Internal room corners
  • External room corners
  • Shower walls

Schlüter-LIPROTEC-LLE  90° corners and end caps

Product image LIPROTEC-LLE 1©Schlüter-Systems KG
Product image LIPROTEC-LLE 2©Schlüter-Systems KG
Product image LIPROTEC-LLE 3©Schlüter-Systems KG
zoom_out_map search
Product image LIPROTEC-LLE 1
Product image LIPROTEC-LLE 2
Product image LIPROTEC-LLE 3










  •










  •










  •










  •










  •










  •










  •










  •










  •










  •











General product information

What this product is made from

Schlüter-LIPROTEC-LLE is available in the following materials:

Profile:

  • AE = anodised aluminium
  • AC = colour coated aluminium

Material properties and areas of application

In applications exposed to chemical or mechanical stresses, the profile’s suitability must be verified. The information provided below is intended as a general guideline.

Schlüter-LIPROTEC-LLE (anodised aluminium): The aluminium features an anodised finish that retains a uniform appearance during normal use.

Surface areas must be protected against abrasion or scratching. Aluminium is sensitive to alkaline media.

Cementitious materials, in conjunction with moisture, become alkaline, which may result in corrosion depending on the concentration and length of exposure (aluminium hydroxide formation).

Remove adhesive or grout immediately from visible areas and don't cover freshly installed assemblies with a protective foil. In addition, ensure that the profile is solidly embedded in the setting material to prevent water from accumulating in small cavities.

Schlüter-LIPROTEC-LLE (colour coated aluminium): The aluminium is pre-treated and powder-coated with a polyurethane covering. The coating is colour-stable, as well as UV- and weather-resistant. Visible edges should be protected against abrasion.

How to look after this product

Schlüter-LIPROTEC-LLE requires no special maintenance or care. Do not use abrasive cleaning agents on the sensitive surfaces. Damaged anodised surfaces can be restored with paint. All cleaning agents must be free of hydrochloric and hydrofluoric acid.

Alcohol (e.g. rubbing alcohol) as well as detergents with a surfactant content over 5% can cause damage to the diffuser lens.

Due to minor heat development of the Schlüter LED strips used in the profile, the expansion of the profile and the utilised diffuser lens may differ.

Profiles retrofitted with the installation clips Schlüter-LIPROTEC-LLE-MK are reversible, including corners and end caps, and can be reused in a different location.
